Technical Specifications
Model Type
Robot Working Radius
1900mm
Effective Welding Size
≤3700mm
Overall Dimensions
1600mm*730mm*1200mm
Packing Dimensions
Main Unit: Approx. 1770 × 1010 × 1470 mm Robot Arm FR20: Approx. 1100 × 500 × 500 mm
Total Machine Weight (Excluding Manipulator)
415kg
Gross Weight (Robot Arm)
61kg
Net Weight (Excluding Robot Arm)
320kg
Robot Unit Weight
≈75kg
Repeat Positioning Accuracy
±0.1mm
The Wire Feeder Is Farther From The Welding Gun
3m (Customizable)
Wire Feeder To Main Body Line
9.5m
Typical Tcp Speed (End-Point Operating Speed)
2m/s
Protection Level
IP54/IP65
Standard Welding Power Source
Ehave2 CM
Rated Output Current
350A/500A
Rated Power
≈25KW/≈16KW
Welding Power Source Weight
34kg
Cooling Method
Air Cooling
Adapted Welding Method
CO₂/MAG/MIG
Weldable Materials
Suitable for high-quality welding of carbon steel and stainless steel
Material & Welding Wire Compatibility
Solid carbon steel, flux-cored carbon steel, solid stainless steel, flux-cored stainless steel
Input Frequency
45～65Hz
Power Supply Requirements
Three-phase 380 V (±15%)
Robot Working Radius
1400mm
Effective Welding Size
≤2600mm
Overall Dimensions
1600mm*730mm*1200mm
Packing Dimensions
Main Unit: Approx. 1770 × 1010 × 1470 mm Robot Arm FR10: Approx. 1000 × 500 × 500 mm
Total Machine Weight (Excluding Manipulator)
415kg
Gross Weight (Robot Arm)
61kg
Net Weight (Excluding Robot Arm)
320kg
Robot Unit Weight
≈40kg
Repeat Positioning Accuracy
±0.05mm
The Wire Feeder Is Farther From The Welding Gun
3m (Customizable)
Wire Feeder To Main Body Line
9.5m
Typical Tcp Speed (End-Point Operating Speed)
1.5m/s
Protection Level
IP54/IP65
Standard Welding Power Source
Ehave2 CM
Rated Output Current
350A/500A
Rated Power
≈25KW/≈16KW
Welding Power Source Weight
34kg
Cooling Method
Air Cooling
Adapted Welding Method
CO₂/MAG/MIG
Weldable Materials
Suitable for high-quality welding of carbon steel and stainless steel
Material & Welding Wire Compatibility
Solid carbon steel, flux-cored carbon steel, solid stainless steel, flux-cored stainless steel
Input Frequency
45～65Hz
Power Supply Requirements
Three-phase 380 V (±15%)
Robot Working Radius
922mm
Effective Welding Size
≤1800mm
Overall Dimensions
1600mm*730mm*1200mm
Packing Dimensions
Main Unit: Approx. 1770 × 1010 × 1470 mm Robot Arm FR5: Approx. 800 × 460 × 470 mm
Total Machine Weight (Excluding Manipulator)
415kg
Gross Weight (Robot Arm)
55kg
Net Weight (Excluding Robot Arm)
320kg
Robot Unit Weight
≈33kg
Repeat Positioning Accuracy
±0.02mm
The Wire Feeder Is Farther From The Welding Gun
3m (Customizable)
Wire Feeder To Main Body Line
9.5m
Typical Tcp Speed (End-Point Operating Speed)
1m/s
Protection Level
IP54/IP65
Standard Welding Power Source
Ehave2 CM
Rated Output Current
350A/500A
Rated Power
≈25KW/≈16KW
Welding Power Source Weight
34kg
Cooling Method
Air Cooling
Adapted Welding Method
CO₂/MAG/MIG
Weldable Materials
Suitable for high-quality welding of carbon steel and stainless steel
Material & Welding Wire Compatibility
Solid carbon steel, flux-cored carbon steel, solid stainless steel, flux-cored stainless steel
Input Frequency
45～65Hz
Power Supply Requirements
Three-phase 380 V (±15%)
Robot Working Radius
622mm
Effective Welding Size
≤1100mm
Overall Dimensions
1600mm*730mm*1200mm
Packing Dimensions
Main Unit: Approx. 1770 × 1010 × 1470 mm Robot Arm FR3: Approx. 800 × 450 × 450 mm
Total Machine Weight (Excluding Manipulator)
415kg
Gross Weight (Robot Arm)
35kg
Net Weight (Excluding Robot Arm)
320kg
Robot Unit Weight
≈21kg
Repeat Positioning Accuracy
±0.02mm
The Wire Feeder Is Farther From The Welding Gun
3m (Customizable)
Wire Feeder To Main Body Line
9.5m
Typical Tcp Speed (End-Point Operating Speed)
1m/s
Protection Level
IP54/IP65
Standard Welding Power Source
Ehave2 CM
Rated Output Current
350A/500A
Rated Power
≈25KW/≈16KW
Welding Power Source Weight
34kg
Cooling Method
Air Cooling
Adapted Welding Method
CO₂/MAG/MIG
Weldable Materials
Suitable for high-quality welding of carbon steel and stainless steel
Material & Welding Wire Compatibility
Solid carbon steel, flux-cored carbon steel, solid stainless steel, flux-cored stainless steel
Input Frequency
45～65Hz
Power Supply Requirements
Three-phase 380 V (±15%)
*The product parameter information provided on this website is for reference only. Please refer to the sales technical solution for specifics.
